Multi-modal Capabilities

VoltAgent supports multi-modal interactions, allowing agents to process and understand inputs that combine different types of content, primarily text and images. This enables more complex and richer interactions, such as asking questions about an uploaded image or providing visual context alongside text prompts.

BaseMessage Content Structure

The core of multi-modal input lies in the structure of the content field within a BaseMessage object. While simple text interactions might use a plain string for content, multi-modal inputs require content to be an array of specific content part objects.

import type { BaseMessage } from "@voltagent/core";

// Basic Text Message
const textMessage: BaseMessage = {
  role: "user",
  content: "Describe this image for me.",
};

// Multi-modal Message (Text + Image)
const multiModalMessage: BaseMessage = {
  role: "user",
  content: [
    {
      type: "text",
      text: "What is shown in this image?",
    },
    {
      type: "image",
      mimeType: "image/jpeg", // Optional but recommended
    },
  ],
};

Content Part Types

When content is an array, each element must be an object with a type field indicating the kind of content. Common types include:

1. Text Part:

   • type: 'text'
   • text: string - The actual text content.

   { type: 'text', text: 'This is the text part.' }

2. Image Part:

   • type: 'image'
   • mimeType?: string - (Optional but Recommended) The MIME type of the image (e.g., image/jpeg, image/png, image/webp). Helps the provider interpret the data correctly.
   • alt?: string - (Optional) Alternative text describing the image.

   {
     type: 'image',
     mimeType: 'image/png',
     alt: 'A cute cat sleeping'
   }

3. File Part (Used less commonly for direct LLM input, but supported):

   • type: 'file'
   • data: string - Base64 encoded file data.
   • filename: string - Original filename.
   • mimeType: string - The MIME type of the file (e.g., application/pdf).
   • size?: number - File size in bytes.

   {
     type: 'file',
     data: 'JVBERi0xLjQKJ...',
     filename: 'report.pdf',
     mimeType: 'application/pdf',
     size: 102400
   }

You can mix different part types within the content array.

Sending Multi-modal Input to Agents

To send multi-modal input, construct your messages array ensuring that the content field for relevant messages is an array of content parts, and pass it to the agent's generation methods (generateText, streamText, generateObject, etc.).

import { Agent } from "@voltagent/core";
import { VercelProvider } from "@voltagent/vercel-ai";

// Assume 'agent' is an initialized Agent instance using the Vercel provider
declare const agent: Agent<VercelProvider>;

async function askAboutImage(imageUrlOrBase64: string, question: string) {
  const messages: BaseMessage[] = [
    {
      role: "user",
      content: [
        { type: "text", text: question },
        {
          type: "image",
          image: imageUrlOrBase64, // Can be Data URI or Base64 string
          // Ensure you provide mimeType if not using a Data URI
          // mimeType: 'image/jpeg'
        },
      ],
    },
  ];

  try {
    // Use generateText for a single response
    const response = await agent.generateText(messages);
    console.log("Agent Response:", response);

    // Or use streamText for streaming responses
    // const streamResponse = await agent.streamText(messages);
    // for await (const chunk of streamResponse.textStream) {
    //   process.stdout.write(chunk);
    // }
    // console.log(); // Newline after stream
  } catch (error) {
    console.error("Error generating response:", error);
  }
}

// Example usage:
askAboutImage(catImageBase64, "What breed is this cat?");

Provider Support & Considerations

Crucially, multi-modal support depends heavily on the specific LLM provider and model you are using.

• Not all models can process images or other non-text modalities.
• Consult the documentation for the underlying model to understand its specific multi-modal capabilities and limitations (e.g., supported image formats, resolutions, token costs for images).

Here's a summary of the official VoltAgent providers:

• @voltagent/google-ai: ✅ Supports Image Input. The provider correctly maps ImagePart data to the format expected by the Google Generative AI SDK (Gemini models).

• @voltagent/groq-ai: ✅ Supports Image Input. The provider maps ImagePart data to the image_url format compatible with Groq API (for models that support vision).

• @voltagent/vercel-ai: ⚠️ Conditional Support. This provider passes the BaseMessage structure (including image parts) to the Vercel AI SDK functions (streamText, generateText). Actual multi-modal support depends entirely on whether the underlying model configured within your Vercel AI SDK setup (e.g., GPT-4 Vision, Claude 3 Haiku/Sonnet/Opus) accepts image input. Check the Vercel AI SDK documentation and your model provider's capabilities.

• @voltagent/xsai: ❌ Does NOT Support Image Input (currently). This provider's toMessage function currently only processes TextPart items from the content array and ignores image or file parts.

See the Providers documentation for more general details on individual providers.

Developer Console Integration

The VoltAgent Developer Console provides a user-friendly way to interact with multi-modal agents:

• Assistant Chat: The chat interface includes an attachment button (📎).
• Uploading: Clicking the button allows you to select one or more image files (and potentially other supported file types) from your computer.
• Preview: Uploaded files are shown as previews below the text input area.
• Sending: When you send the message, the Console automatically converts the uploaded files into the appropriate ImagePart or FilePart format (using Base64 data URIs) and constructs the BaseMessage with the content field as an array containing both your typed text and the file/image parts. This structured message is then sent to the agent API.

This provides a seamless way for you and your users to test and utilize the multi-modal capabilities of your agents directly within the Console.
